Overall Dimensions | mm | 6.000 x 2.100 x 2.670 |
Wheelbase | mm | 3.300 |
Wheel tracks (front/rear) | mm | 1.742/1.538 |
Ground clearence | mm | 190 |
Ceiling height | mm | 1.900 |
Curb weight | kg | 2.880 |
Gross vehicle weight | kg | 4.160 |
Seat | 16 |
Model | FIAT POWERTRAIN F1C | |
Type | Diesel, 4 strokes, 4 inline cylinders, turbocharger with intercooler, common rail injection system | |
Displacement | cc | 2.998 |
Bore x Stroke | mm | 95.8 x 104 |
Max Power/rpm | Ps / rpm | 146 / 3.500 |
Max Moment/rpm | N.m/rpm | 370 / 1.400 - 2.900 |
Clutch | 01 dry single plate, hydraulic operation | |
Gearbox | FIAT POWERTRAIN FPT2840.6 (6 speeds) |
Steering system | Rack and Pinion Type, hydraulic operation |
Braking system (Front/Rear) | Disc brake/Disc brake, hydraulic operation, vacuum booster assistance with ABS/EBD |
Front | Independent, lateral leaf spring and hydraulic absorbers. | |
Rear | Dependent, leaf spring and hydraulic absorbers. |
Front/Rear | Front : Simple 195/75R16 | Rear: Twin tires 195/75R16 |
Turing circle | m | 6.1 |
Top speed | km/h | 130 |
Fuel tank | L | 100 |
